The WSEB50 50/13 is a 45mm mechanical limits motor with a built in receiver, perfect for roller shutters.
| Rated Torque (N.m) | 50 |
| Speed (RPM) | 13 |
| Nominal Consumption (W) | 244 |
| Nominal Voltage (V) AC | 240 |
| Nominal Current (A) | 1.06 |
| Running Time (mins) | 4 |
| Protection Index (IP) | 44 |
| Total Length (mm) | 570 |
| Maximum Turns (turn) | 27 |
| Net Weight (Kg) | 2.6 |
| INCLUDED C&D | A2404 |
| INCLUDED MOTOR BRACKET | A3415 |
