Alpha’s new 240 volt 2/31 motor can fit a 38mm tube and lift a 3m x 3m unlinked internal roller blind, delivering optimal performance.
AC 120-240V power supply
Built-in transformer
Electronic limit switch
Built-in receiver
3rd intermediate limit position
Compact design
25mm diameter
3 adjustable speeds
Motor can fit 38mm tube
| Rated Torque (Nm) | 2 |
| Speed (rpm) | 25/30/35 |
| Lifting Capacity (m) | 3×3 |
| Nominal Consumption (W) | 13.6 |
| Nominal Voltage (V) | 100-240 |
| Nominal Current (A) | 0.24 |
| Running Time (mins) | 4 |
| Protection Index (IP) | 20 |
| Total Length (mm) | 532 |
| Maximum Turns (turn) | Infinity |
| Net Weight (kg) | 0.5 |
| Included C&D | A2310 |
